Description
Functionality
- Fitness sorting
- New/old style note sorting
- Orientation sorting
- Denomination sorting
- Batching arrangement
- Serial numbers reading (optional)
Features
- Simple selection of operating modes
- User-friendly color LCD
- Rapid transport and accurate sorting
- Small footprint for teller areas
- Superb counterfeit detection
- Fast and reliable deposit verification
- Ease to upgrade software and to be maintained
Speed
- Counting: Up to 1,000 BN/min
- Fitness detection: Up to 800 BN/min
- The speed levels are available for manual setting
Feed Capacity
- Hopper: 1200 notes with continuous feed
Capacity of Output Stackers
- Stacker: 500 notes x 4
- Reject stacker: 150 notes x 2
Detection Methods
- Visible light image analysis
- Infrared image analysis
- Transmitted light image analysis
- Ultraviolet fluorescence analysis
- Full length magnetic analysis
- Full size thickness detection
- Double side contact image scan
Detection Type
- Soiling, hole, adhesive tape, missing part, dog-ears, stain, tear
Ports
- RS-232
- USB
- Rj45
Sound Power
- Idle: ＜65db(A)
Electrical Specifications
- Voltage: 220V AC, 50Hz
- Power consumption: ≤450W
Operating Environment
- Temperature: -10oC to 45oC
- Humidity: 20% to 95% Non-condensing
Dimensions and Weight
- Dimension: 600mm X 600mm X 440mm (H x W x D)
- Weight: approx. 80kg
